Network Standard
|
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
|
|
Product Segment
|
AX3000 ultimate AX performance :
2402 Mbps+ 574 Mbps
|
|
WiFi Data Rate
|
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps
|
|
Antenna
|
Internal dual-band antenna x 2
|
|
Transmit / Receive
|
2.4GHz 2x2
5GHz 2x2
|
|
Processor
|
1.7 GHz quad-core processor
|
|
Memory
|
128 MB Flash
512 MB RAM
|
|
Boosts Speed
|
MIMO technology
|
|
Operating Frequency
|
2.4 GHz
5 GHz
|
|
Operating Mode
|
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
|
|
I/O Ports
|
RJ45 for Gigabits BaseT for WAN/LAN
x 1
RJ45 for Gigabits BaseT for LAN x1
|
|
Buttons
|
WPS Button, Reset Button
|
|
LED Indicator
|
Power x 1
|
|
Power Supply
|
AC Input: 110V~240V(50~60Hz)
DC Output: 12 V with max. 1.5 A current
|
|
Product Weight (g)
|
307 g
|
|
Product Dimensions
|
90 x 90 x 85 mm
|
|
AiMesh
|
AiMesh
• Primary AiMesh Router
• AiMesh Node
|
|
Parental Control
|
"Allow you to block access to
unwanted websites and apps."
Time Scheduling
Reward
Parental Control - Safe Browsing
Customized Internet Schedule
|
|
Router APP
|
APP: ASUS Router APP
|
|
Guest Network
|
"The Guest Network provides
Internet connection for guests but restricts access to your local
network."
Support Guest Network
• Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3
Guest Network Connection Time Limit
Open system, WPA/WPA2/WPA3-Personal
|
|
Security
|
AiProtection
VPN
WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
|
|
AiProtection
|
AiProtection Classic
• Router Security Assessment
• Malicious Site Blocking
• Infected Device Prevention and Blocking
|
|
VPN
|
Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
|
|
Traffic Control
|
• Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
|
|
WAN
|
Internet connection Type : PPPoE,
PPTP, L2TP, Automatic IP, Static IP
Internet Connection Type
• PPPoE
• PPTP
• L2TP
• Automatic IP
• Static IP
Port Forwarding
• Maximum Port Forwarding Rule : 64
Port Triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
|
|
LAN
|
DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
|
|
Wireless
|
UTF-8 SSID
WiFi MAC Address Filter
• Maximum MAC Filters : 64
Wireless Scheduler
Airtime Fairness
Universal Beamforming
Explicit Beamforming
|
|
Administration
|
Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
|
