Model
|
RT-AC750L
|
|
Network Standard
|
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
IPv4
IPv6
IEEE 802.11e
IEEE 802.11i
|
|
WiFi Data Rate
|
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 433 Mbps
|
|
Antenna
|
External antenna x 4
|
|
Transmit / Receive
|
MIMO technology
2.4GHz 2x2
5GHz 2x2
|
|
Memory
|
16 MB Flash
64 MB RAM
|
|
Operating Frequency
|
2.4GHz
5GHz
|
|
Operating Mode
|
Accesspoint, Router
|
|
I/O Ports
|
RJ45 for 10/100Mbps BaseT for WAN x
1
RJ45 for 10/100Mbps BaseT for LAN x 4
|
|
Buttons
|
WPS Button, Reset Button, Power
Button
|
|
Power Supply
|
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 0.5 A current
|
|
Package Content
|
RT-AC750L Wi-Fi router
1 x RJ-45 cable
1 x Power adapter
1 x QSG
1 x Warranty card
|
|
Product Weight (g)
|
271 g
|
|
Product Dimensions
|
177 x126 x 34 ~ mm (WxDxH)
|
|
Parental Control
|
"Allow you to block access to
unwanted websites and apps."
Customized Internet Schedule
|
|
Guest Network
|
"The Guest Network provides
Internet connection for guests but restricts access to your local
network."
• Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3
Guest Network Connection Time Limit
Guest Network Encryption : Open system, WPA/WPA2-Personal
|
|
Security
|
Open system, WPA/WPA2-Personal,
WPA/WPA2-Enterprise
WPS
SSH
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
|
|
Traffic Control
|
• Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
-- Maximum Traditional QoS Rule : 32
Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
• Traffic Analysis Period : Daily, Weekly, Monthly
|
|
WAN
|
Internet connection Type : PPPoE,
PPTP, L2TP, Automatic IP, Static IP
Port forwarding
• Maximum Port Forwarding Rule : 64
Port triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
|
|
LAN
|
DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
|
|
Wireless
|
UTF-8 SSID
WiFi MAC Address Filter
• Maximum MAC Filters : 64
Wireless Scheduler
Airtime Fairness
RADIUS Client
Explicit Beamforming
|
|
USB application
|
File System : FAT16, FAT32, NT3G
|
|
Administration
|
Configuration Backup and Restore
Diagnosis tools
Feedback System
System Log
|
