ATX Version
ATX 12V V2.52
PFC
Active PFC
Input Voltage
100-240V
Input Current
15-7A
Input Frequency
47-63Hz
Dimensions (L x W x H)
180 x 150 x 86 mm
Fan Size
140mm
Fan Bearing
FDB
Fan Speed
2200 RPM
Noise Level @ 20%
0 dBA
Noise Level @ 50%
15.8 dBA
Noise Level @ 100%
30.1 dBA
Efficiency
≥90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Operating Temperature
0-50°C
Power Good Signal
100 - 150 ms
Hold Up Time
>20ms at 100% Load
MTBF
>100,000 Hours
Protections
UVP / OVP / OPP / OTP / SCP / OCP
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
EPS 8 Pin Connector
SATA Connectors
12
Peripheral 4 Pin Connectors
4
PCI-e 6+2 Pin Connectors
8
Warranty
10 Years
Series
MWE Gold Series
Category
Above 750W
Modular
Fully Modular
80 Plus Efficiency
Gold
