Basic
Specifications / Copy Function
|
|
|
Item
|
Apeos
C325 z
|
|
Type
|
Desktop
|
|
Memory
Capacity
|
512 MB
(Max: 512 MB)
|
|
Storage
Device Capacity
|
-
|
|
Colour
Capability
|
Full
Colour
|
|
Scan
Resolution
|
600 x
600 dpi
|
|
Printing
Resolution
|
600 x
2400 dpi
|
|
Warm-up
Time*1
|
35
seconds or less (23 degrees Celsius room temperature)
|
|
Recovery
Time (Recovery Time from Sleep Mode)*1
|
17
seconds or less (23 degrees Celsius room temperature)
|
|
Original
Size
|
Maximum
of A4, Letter, Legal*2 for both Sheet and Book
|
|
Paper
Size
|
|
|
Max
|
A4,
Letter, Legal
|
|
Min
|
A6, 76
x 127 mm
|
|
loss width
|
Lead
edge 4.1 mm, Trail edge 4.1 mm, Right/Left edge 4.1 mm
|
|
Paper
Weight*3
|
|
|
Paper
Tray
|
60 to
176 gsm
|
|
Bypass
Tray
|
60 to
176 gsm
|
|
First
Copy Output Time*4
|
B/W:
9.5 sec. (A4) Colour: 12.0 sec. (A4)
|
|
Continuous
Copy Speed*5
|
|
|
A4
|
B/W: 31
ppm Colour: 31 ppm
|
|
A5
|
B/W: 41
ppm Colour: 41 ppm
|
|
Paper
Tray Capacity*6
|
|
|
Standard
|
Standard
Tray: 250 sheets Bypass Tray: 50 sheets
|
|
Optional
|
250
Sheets Feeder Unit: 250 sheets
|
|
Max
|
550
sheets [Standard + 250 Sheets Feeder Unit]
|
|
Output
Tray Capacity*6
|
150
sheets (Face down)
|
|
Power
Supply
|
AC220-240
V +/- 10 %, 10 A, 50/60 Hz common
|
|
Maximum
Power Consumption
|
1120 W
Sleep Mode: 0.5 W Low Power Mode: 11 W Ready Mode: 41 W
|
|
Dimensions
|
W 410 x
D 430 x H 366 mm
|
|
Weight*7
|
20.6 kg
|
|
Scan
Function
|
|
|
Type
|
Colour
Scanner
|
|
Scan
Resolution
|
|
|
Scan to
PC
|
TWAIN:
50 x 50 to 9600 x 9600 dpi
WIA :
75 dpi, 100 dpi, 150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
|
|
Scan to
Network / e-mail
|
200
dpi, 300 dpi, 400 dpi*¹, 600 dpi*¹
|
|
Scan
Speed
|
Same as
the Scan Speed for the Automatic Document Feeder
|
|
Interface
|
|
|
Standard
|
Ethernet
1000BASE-T / 100BASE-TX / 10BASE-T, USB2.0
Wireless
LAN (IEEE 802.11 b / g / n)
|
|
Fax
Function
|
|
|
Original
Size
|
Scanner
Glass: Max A4, Letter Automatic Document Feeder: Max Legal
|
|
Recording
Paper Size
|
Max:
Legal; Min: A4, Letter
|
|
Transmission
Time
|
3
seconds and more but fewer than 4 seconds*1
|
|
Transmission
Mode
|
ITU-T
G3
|
|
Applicable
Lines
|
Telephone
subscriber line, PBX, Maximum 1 port*² (G3-1 port)
|
