General
|
|
|
CPU Model
|
Intel Core i5-12600K (12th Gen)
|
|
CPU Socket
|
LGA 1700
|
|
Manufacturing Process
|
10 nm
|
|
Maximum CPU Configuration
|
1S
|
|
Maximum Number of PCIe Lanes
|
16 (Revision 5.0)
4 (Revision 4.0)
|
|
Unlocked
|
Yes
|
|
Performance
|
|
|
Number of Cores
|
10 (6 x P-Cores + 4 x E-Cores)
|
|
Number of Threads
|
16
|
|
Base Clock Speed
|
P-Core: 3.7 GHz
E-Core: 2.8 GHz
|
|
Maximum Boost Speed
|
P-Core Turbo: 4.9 GHz
E-Core Turbo: 3.6 GHz
|
|
L3 Cache
|
20 MB
|
|
Memory Support
|
|
|
Maximum Capacity
|
128 GB
|
|
Memory Support
|
DDR4 Up to 3200 MT/s
DDR5 Up to 4800 MT/s
|
|
ECC Memory
|
Yes
|
|
Channel Architecture
|
Dual Channel
|
|
Maximum Memory Bandwidth
|
76.8 GB/s
|
|
Optane Memory Support
|
Yes
|
|
Power
|
|
|
Thermal Design Power (TDP, Max)
|
125 W
|
|
Included Thermal Solution
|
No
|
|
Maximum Temperature
|
212°F / 100°C
|
|
Thermal Monitoring Technologies
|
Yes
|
|
Technology
|
|
|
AES Support
|
Yes
|
|
Extension
|
AVX 2.0, AVX-512, SSE 4.1/4.2
|
|
Instruction Set
|
64-Bit
|
|
Virtualization
|
Yes: Intel VT-d, Intel VT-x, Intel VT-x with
Extended Page Tables (EPT)
|
|
DMI
|
DMI4 (16 GT/s)
|
|
vPro Support
|
Yes
|
|
Performance Technologies
|
Deep Learning Boost, Gaussian and Neural Accelerator 3.0,
Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Stable Image
Platform Program, Turbo Boost 2.0
|
|
Security Technologies
|
Control-Flow Enforcement (CET), Device Protection
with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS
Guard, Secure Key, Software Guard Extensions, Threat Detection Technology
(TDT), Trusted Execution Technology
|
|
Video Technologies
|
Clear Video, Clear Video HD, InTru 3D, Quick Sync Video
|
|
Integrated Graphics
|
|
|
Integrated Graphics
|
Intel UHD Graphics 770
|
|
Maximum Resolution Support
|
7680 x 4320 at 60 Hz
|
|
Supported APIs
|
DirectX: 12
OpenGL: 4.5
|
|
Number of Displays
|
4
|
|
Output Support
|
DisplayPort, HDMI
|
|
Base Clock Speed
|
300 MHz
|
|
Maximum Boost Speed
|
1.45 GHz
|
