General
|
|
|
CPU
Model
|
Intel
Core i7-13700 (13th Gen)
|
|
CPU
Socket
|
LGA
1700
|
|
Manufacturing
Process
|
10 nm
|
|
Maximum
CPU Configuration
|
1S
|
|
Maximum
Number of PCIe
Lanes
|
16
(Revision 5.0)
4
(Revision 4.0)
|
|
Unlocked
|
No
|
|
Performance
|
|
|
Number
of
Cores
|
16 (8 x
P-Cores + 8 x E-Cores)
|
|
Number
of Threads
|
24
|
|
Base
Clock Speed
|
P-Core:
2.1 GHz
E-Core:
1.5 GHz
|
|
Maximum
Boost Speed
|
P-Core
Turbo: 5.1 GHz
E-Core
Turbo: 4.1 GHz
|
|
L3
Cache
|
30 MB
|
|
Memory
Support
|
|
|
Maximum
Capacity
|
128 GB
|
|
Memory
Support
|
DDR5 Up
to 5600 MT/s
DDR4 Up
to 3200 MT/s
|
|
ECC
Memory
|
Yes
|
|
Channel
Architecture
|
Dual
Channel
|
|
Maximum
Memory Bandwidth
|
89.6
GB/s
|
|
Optane
Memory
Support
|
Yes
|
|
Power
|
|
|
Thermal
Design Power (TDP, Max)
|
65 W
|
|
Included
Thermal Solution
|
Laminar
RM1 (65 W)
|
|
Maximum
Temperature
|
212°F /
100°C
|
|
Thermal
Monitoring
Technologies
|
Yes
|
|
Technology
|
|
|
AES
Support
|
Yes
|
|
Extension
|
AVX
2.0, AVX-512, SSE 4.1/4.2
|
|
Instruction
Set
|
64-Bit
|
|
Virtualization
|
Yes:
Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT)
|
|
DMI
|
DMI4
(16 GT/s)
|
|
vPro
Support
|
Yes
|
|
Performance
Technologies
|
Deep
Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel
Thread Director, SpeedShift, SpeedStep, Stable Image Platform Program, Turbo
Boost 2.0, Turbo Boost Max 3.0
|
|
Security
Technologies
|
Control-Flow
Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit,
MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard
Extensions, Threat Detection Technology (TDT), Trusted Execution Technology
|
|
Video
Technologies
|
Clear
Video, Clear Video HD, InTru 3D, Quick Sync Video
|
|
Integrated
Graphics
|
Intel
UHD Graphics 770
|
|
Maximum
Resolution Support
|
7680 x
4320 at 60 Hz
|
|
Supported
APIs
|
DirectX:
12
OpenGL:
4.5
|
|
Number
of Displays
|
4
|
|
Output
Support
|
DisplayPort,
HDMI
|
|
Base
Clock Speed
|
300 MHz
|
|
Maximum
Boost Speed
|
1.45
GHz
|
