Camera
|
|
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
|
Min.
Illumination
|
0.0035
@ F1.0 (1/30 s, AGC ON), 0 Lux with LED on
|
|
Shutter
Speed
|
1/3 s
to 1/100,000 s
|
|
Slow
Shutter
|
Yes
|
|
Wide
Dynamic Range
|
120 dB
|
|
Angle
Adjustment
|
Pan: 0°
to 360°, tilt: 0° to 75°, rotate: 0° to 360°
|
|
Lens
|
|
|
Focus
|
Fixed
|
|
Lens
Type
|
2.8/4/6
mm
|
|
FOV
|
2.8 mm,
horizontal FOV: 112°, vertical FOV: 57°, diagonal FOV: 138°; 4 mm, horizontal
FOV: 89°, vertical FOV: 46°, diagonal FOV: 106°；6 mm,
horizontal FOV: 56°, vertical FOV: 30°, diagonal FOV: 66°；
|
|
Aperture
|
F1.0
|
|
Lens
Mount
|
M16
|
|
Illuminator
|
|
|
White
Light Range
|
Warm
white LEDs (3000K), up to 30m
|
|
Video
|
|
|
Max.
Resolution
|
1920 ×
1080
|
|
Main
Stream
|
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 ×
960, 1280 × 720)
|
|
Sub
Stream
|
50Hz:
25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360,
320 × 240)
|
|
Third
Stream
|
50Hz:
1fps (1280 × 720, 640 × 480, 640 × 360, 352 × 240, 320 × 240); 60Hz: 1fps
(1280 × 720, 640 × 480, 640 × 360, 352 × 240, 320 × 240)
|
|
Video
Compression
|
Main
stream: H.265+/H.265/H.264+/H.264, Sub stream: H.265/H.264/MJPEG, Third
stream: H.265/H.264
|
|
Video
Bit Rate
|
32 Kbps
to 8 Mbps
|
|
H.264
Type
|
Baseline
Profile/Main Profile/High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Scalable
Video Coding (SVC)
|
H.265
encoding and H.264 encoding support
|
|
Region
of Interest (ROI)
|
Support
1 fixed region for main stream
|
|
Network
|
|
|
Simultaneous
Live View
|
Up to 6
channels
|
|
API
|
ONVIF
(PROFILE S, PROFILE G), ISAPI
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
|
|
User/Host
|
Up to
32 users, 3 levels: Administrator, Operator and User
|
|
Network
Storage
|
Support
micro SD/SDHC/SDXC card (128 G) local storage, NAS (NFS, SMB/CIFS), ANR
|
|
Client
|
iVMS-4200,
Hik-Connect, iVMS-4500, iVMS-5200
|
|
Web
Browser
|
IE8+,
Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
|
|
Alarm
Trigger
|
Motion
detection, video tampering detection, network disconnected, IP address
conflict, illegal login, HDD full, HDD error
|
|
|
|
|
DNR
|
3D DNR
|
|
Enhancement
|
BLC/3D
DNR/HLC
|
|
Settings
|
Rotate
mode, saturation, brightness, contrast, sharpness, AGC, white balance
adjustable by client software or web browser
|
|
Interface
|
|
|
On-board
Storage
|
Built-in
micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Hardware
Reset
|
Yes
|
|
Communication
Interface
|
1 RJ45
10M/100M self-adaptive Ethernet port
|
|
Event
|
|
|
Smart
Event
|
Line
crossing detection, intrusion detection
|
|
General
|
|
|
Firmware
Version
|
V5.5.53
|
|
General
Function
|
One-key
reset, three streams, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filter
|
|
Startup
and Operating Conditions
|
-30 °C
to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
|
|
Power
Supply
|
12 VDC
± 25%, 5.5 mm coaxial power plug,PoE (802.3af, class 3)
|
|
Power
Consumption and Current
|
12 VDC,
0.5 A, max: 5 W; PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max: 6.5 W
|
|
Camera
Dimension
|
Camera:
Φ130 × 103.6 mm (Φ5.1″ × 4.1″)
|
|
Camera
Weight
|
Camera:
500 g (1.1 lb.)
|
|
Approval
|
|
|
Protection
|
IP67
|
