Camera
|
|
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
|
Max.
Resolution
|
1920 ×
1080
|
|
Min.
Illumination
|
0.01Lux
@ (F1.2, AGC ON), 0 Lux with IR
|
|
Shutter
Time
|
1/3 s
to 1/100,000 s
|
|
Day
& Night
|
IR cut
filter with auto switch
|
|
Lens
|
|
|
Focal
Length & FOV
|
2.8 mm,
horizontal FOV: 105.8°
|
|
Lens
Mount
|
M12
|
|
Illuminator
|
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
Up to
10 m
|
|
Video
|
|
|
Main
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 ×720)
60 Hz:
30 fps (1920 × 1080, 1280 ×720)
|
|
Sub-Stream
|
50 Hz:
25 fps (704 × 576, 352 × 288, 640 × 480, 320 × 240)
60 Hz:
30 fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)
|
|
Video
Compression
|
Main
stream: H.265+/H.264+/H.265/H.264
Sub
stream: H.265/H.264/MJPEG
|
|
Video
Bit Rate
|
32 Kbps
to 8 Mbps
|
|
H.264
Type
|
Baseline
Profile/Main Profile
|
|
Region
of Interest (ROI)
|
1 fixed
region for each stream
|
|
Audio
|
|
|
Audio
Type
|
Mono
sound
|
|
Audio
Compression
|
G.711/G.722.1/G.726/MP2L2/PCM
|
|
Audio
Bit Rate
|
64
Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 160 Kbps(MP2L2)
|
|
Audio
Sampling Rate
|
Max. 16
kHz
|
|
Environment
Noise Filtering
|
Yes
|
|
Network
|
|
|
Security
|
64/128-bit
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
|
|
Wi-Fi
|
|
|
Wi-Fi
Protocol
|
802.11b:
CCK, QPSK, BPSK
802.11g/n:
OFDM
|
|
Frequency
Range
|
2.4 GHz
- 2.4835 GHz
|
|
Channel
Bandwidth
|
20/40
MHz
|
|
Transfer
Rate
|
11b:
11Mbps
11g:
54Mbps
11n: up
to 150Mbps
|
|
Wireless
Range
|
Up to
50 m (The performance varies based on actual environment)
|
|
|
|
|
Settings
|
Brightness,
saturation, sharpness, contrast are adjustable via client software
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Wide
Dynamic Range (WDR)
|
Digital
WDR
|
|
Enhancement
|
BLC
|
|
Interface
|
|
|
On-Board
Storage
|
Built-in
memory card slot, support Micro SD/SDHC/SDXC, up to 128 GB
|
|
Alarm
|
Video
Tampering Alarm, HDD Full, HDD Error, Network Disconnected, IP Address
Conflicted, Illegal Login
|
|
Event
|
|
|
Basic
Event
|
Motion
detection, video tampering alarm, HDD full, HDD error, network disconnected,
IP address conflicted, illegal login
|
|
General
|
|
|
Power
|
5 VDC ±
15%, max. 0.9 A, max. 4.5 W, micro USB interface
|
|
Material
|
Plastic
|
|
Dimension
|
Ø64 ×
106.9 mm (Ø2.52'' × 4.21'')
|
|
Weight
|
115 g
(0.25 lbs)
|
|
Startup
and Operating Conditions
|
-10 °C
to 40°C (14 °F to 104 °F), humidity 95% or less (non-condensing)
|
|
General
Function
|
One-key
reset, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask,
Watermark
|
