Picture/Display
|
|
|
Panel Size
|
34 inch / 86.36 cm
|
|
Aspect ratio
|
21:9
|
|
LCD panel type
|
VA LCD
|
|
Backlight type
|
W-LED system
|
|
Pixel pitch
|
0.23175 x 0.23175 mm
|
|
Brightness
|
300 cd/m²
|
|
Display
colours
|
16.7 M
|
|
Colour gamut
(typical)
|
NTSC 100%*, sRGB 119%*, Adobe RGB
90%*
|
|
Contrast ratio
(typical)
|
3000:1
|
|
SmartContrast
|
80,000,000 :1
|
|
Response time
(typical)
|
4 ms (Grey to Grey)*
|
|
Viewing angle
|
178º (H)/178º (V)
@ C/R > 10
|
|
enhancement
|
SmartImage
|
|
Maximum
resolution
|
3440 x 1440 @ 100 Hz*
|
|
Effective
viewing area
|
797.2 (H) x 333.7 (V) — at a
1500 R curvature*
|
|
Scanning
Frequency
|
30–160 kHz (H)/48–100 Hz
(V)
|
|
sRGB
|
Yes
|
|
Delta E
|
< 2 (sRGB)
|
|
Flicker-free
|
Yes
|
|
Pixel Density
|
110 PPI
|
|
LowBlue Mode
|
Yes
|
|
Display Screen
Coating
|
Anti-Glare, 2H, Haze 25%
|
|
SmartUniformity
|
93 ~ 105%
|
|
EasyRead
|
Yes
|
|
Adaptive sync
|
Yes
|
|
Connectivity
|
|
|
Signal Input
|
DisplayPort 1.2 x 1, HDMI 2.0 x 2
|
|
Sync Input
|
Separate Sync
Sync on Green
|
|
Audio (In/Out)
|
Headphone out
|
|
USB:
|
USB-B x 1 (upstream), USB 3.2 x 4
(downstream with 1 fast charge B.C. 1.2)
|
|
HDCP
|
HDCP 1.4 (DP), HDCP 2.2 (HDMI)
|
|
Convenience
|
|
|
Built-in
Speakers
|
5 W x 2
|
|
Plug and Play
Compatibility
|
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7
|
|
User
convenience
|
SmartImage
Input
User
Menu
Power On/Off
|
|
OSD Languages
|
Brazil Portuguese
Czech
Dutch
English
French
Finnish
German
Greek
Hungarian
Italian
Japanese
Korean
Portuguese
Polish
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukrainian
|
|
Other
convenience
|
Kensington lock
VESA mount (100 x 100 mm)
|
|
Control
software
|
SmartControl
|
|
MultiView
|
PIP/PBP mode*
2 x devices
|
|
Stand
|
|
|
Height
adjustment
|
180 mm
|
|
Swivel
|
-180/180 degree
|
|
Tilt
|
-5/30 degree
|
|
Power
|
|
|
ECO mode
|
34 W (typ.)
|
|
Power supply
|
Built-in
100–240 VAC, 50–60 Hz
|
|
Off mode
|
Zero watts with Zero switch
|
|
On mode
|
28.36 W (typ.) (EnergyStar test
method)
|
|
Standby mode
|
0.3 W (typ.)
|
|
Power LED
indicator
|
Operation – White
Standby mode - White (flashing)
|
|
Energy Label
Class
|
F
|
|
Dimensions
|
|
|
Packaging in
mm (W x H x D)
|
904 x 525 x 282 mm
|
|
Product
without stand (mm)
|
807 x 367 x 110 mm
|
|
Product with
stand (max height)
|
807 x 601 x 250 mm
|
|
Weight
|
|
|
Product with
packaging (kg)
|
15.05 kg
|
|
Product with
stand (kg)
|
11.32 kg
|
|
Product
without stand (kg)
|
7.62 kg
|
|
Operating conditions
|
|
|
Altitude
|
Operation: +12,000 ft
(3658 m), Non-operation: +40,000 ft (12,192 m)
|
|
Temperature
range (operation)
|
0°C to 40 °C
|
|
Relative
humidity
|
20%-80 %
|
|
Temperature
range (storage)
|
-20°C to 60 °C
|
|
MTBF
(demonstrated)
|
70,000 hrs (excluded backlight)
|
|
Sustainability
|
|
|
Environmental
and energy
|
PowerSensor
LightSensor
EnergyStar 8.0
TCO Certified
RoHS
|
|
Recyclable
packaging material
|
100 %
|
|
Specific
Substances
|
Mercury free
PVC/BFR free housing
|
|
Compliance and standards
|
|
|
Regulatory
Approvals
|
CB
EPA
cETLus
FCC Class B
ICES-003
CE Mark
TUV/GS
TUV Ergo
CU-EAC
UKRAINIAN
|
|
Cabinet
|
|
|
Finish
|
Texture
|
|
Foot
|
Black
|
|
Front bezel
|
Black
|
|
Rear cover
|
Black
|
