Picture/Display
|
|
|
Panel Size
|
15.6 inch / 39.6 cm
|
|
Aspect ratio
|
16:9
|
|
LCD panel type
|
IPS technology
|
|
Backlight type
|
W-LED system
|
|
Pixel pitch
|
0.17925 x 0.17925 mm
|
|
Brightness
|
250 cd/m²
|
|
Display colors
|
16.2 M
|
|
Color gamut
(typical)
|
NTSC 46%*, sRGB 64%*
|
|
Contrast ratio
(typical)
|
700:1
|
|
SmartContrast
|
50,000,000:1
|
|
Response time
(typical)
|
4 ms (Gray to Gray)*
|
|
Viewing angle
|
170º (H) / 170º (V)
@ C/R > 10
|
|
enhancement
|
SmartImage
|
|
Maximum
resolution
|
1920 x 1080 @ 75 Hz*
|
|
Effective
viewing area
|
344.16 (H) x 193.59 (V)
|
|
Scanning
Frequency
|
Landscape mode: HDMI 30 - 140 kHz
(H), USB-C 30 - 85 kHz (H) / 48 - 75 Hz (V)
Portrait mode: 30 - 150 kHz (H) / 48 - 75 Hz (V)
|
|
sRGB
|
Yes
|
|
Flicker-free
|
Yes
|
|
Pixel Density
|
141 PPI
|
|
LowBlue Mode
|
Yes
|
|
Display Screen
Coating
|
Anti-Glare, 3H, Haze 25%
|
|
EasyRead
|
Yes
|
|
HDR
|
HDR 10 supported
|
|
Connectivity
|
|
|
Signal Input
|
micro HDMI 2.0 x 1, USB-C x 1
(DisplayPort 1.4 Alt mode and Power Delivery)
|
|
Sync Input
|
Separate Sync
|
|
Audio (In/Out)
|
Audio out
|
|
HDCP
|
HDCP 1.4 (HDMI / USB-C), HDCP 2.2
(HDMI / USB-C)
|
|
Power Delivery
|
|
|
Version
|
USB PD version 3.0
|
|
USB-C (input)
|
up to 65W (5V/3A, 7V/3A, 9V/3A,
10V/3A, 12V/3A, 15V/3A, 20V/3.25A)
|
|
USB-C (output)
|
up to 15W (5V/3A)
|
|
Convenience
|
|
|
Plug &
Play Compatibility
|
DDC/CI
Mac OS X
sRGB
Windows 11 / 10 / 8.1 / 8 / 7
|
|
User
convenience
|
SmartImage
Input
Menu
Power On/Off
|
|
OSD Languages
|
Brazil Portuguese
Czech
Dutch
English
French
Finnish
German
Greek
Hungarian
Italian
Japanese
Korean
Portuguese
Polish
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukrainian
|
|
Other convenience
|
VESA mount: Yes*
|
|
Control software
|
SmartControl
|
|
Stand
|
|
|
Pivot
|
+90 degree
|
|
Tilt
|
0 ~ 90 degree
|
|
Power
|
|
|
ECO mode
|
5.5 W (typ.)
|
|
Power supply
|
External
100-240VAC, 50-60Hz
|
|
Off mode
|
0.3 W (typ.)
|
|
On mode
|
8.2 W (typ.) (EnergyStar test method)
|
|
Standby mode
|
0.3 W (typ.)
|
|
Power LED
indicator
|
Operation – White
Standby mode- White (blinking)
|
|
Dimensions
|
|
|
Packaging in
mm (WxHxD)
|
400 x 281 x 103 mm
|
|
Product with
stand(max height)
|
359 x 232 x 119 mm
|
|
Weight
|
|
|
Product with
packaging (kg)
|
2.45 kg
|
|
Product with
stand (kg)
|
1.03 kg
|
|
Operating conditions
|
|
|
Altitude
|
Operation: +12,000ft (3,658m),
Non-operation: +40,000ft (12,192m)
|
|
Temperature
range (operation)
|
0°C to 40 °C
|
|
Relative
humidity
|
20%-80 %
|
|
Temperature
range (storage)
|
-20°C to 60 °C
|
|
MTBF
(demonstrated)
|
70,000 hrs (excluded backlight)
|
|
Sustainability
|
|
|
Environmental
and energy
|
EnergyStar 8.0
RoHS
|
|
Post consumer
recycled plastic
|
60%
|
|
Recyclable
packaging material
|
100 %
|
|
Specific
Substances
|
Mercury free
PVC / BFR free housing
|
|
Compliance and standards
|
|
|
Regulatory
Approvals
|
CB
CE Mark
FCC Class B
ICES-003
PSB
|
|
Cabinet
|
|
|
Finish
|
Texture
|
|
Foot
|
Black
|
|
Front bezel
|
Black
|
|
Rear cover
|
Black
|
