Overview
|
|
|
Application
|
Client PCs, Game Consoles
|
|
Interface
|
PCIe Gen 4.0 x4, NVMe 1.3c
|
|
Sequential Read
|
Up to 7,000 MB/s * Performance may vary based on system hardware
& configuration
|
|
General Feature
|
|
|
Application
|
Client PCs, Game Consoles
|
|
Capacity
|
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be
less (due to formatting, partitioning, operating system, applications or
otherwise)
|
|
Form Factor
|
M.2 (2280)
|
|
Interface
|
PCIe Gen 4.0 x4, NVMe 1.3c
|
|
Dimension (WxHxD)
|
80 x 24 x 8.6 mm (with heatsink)
|
|
Weight
|
Max 30.5g
|
|
Storage Memory
|
Samsung V-NAND 3-bit MLC
|
|
Controller
|
Samsung in-house Controller
|
|
Cache Memory
|
Samsung 1GB Low Power DDR4 SDRAM
|
|
Special Feature
|
|
|
TRIM Support
|
Supported
|
|
S.M.A.R.T Support
|
Supported
|
|
GC (Garbage Collection)
|
Auto Garbage Collection Algorithm
|
|
Encryption Support
|
AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted
drive)
|
|
WWN Support
|
Not supported
|
|
Device Sleep Mode Support
|
Yes
|
|
Performance
|
|
|
Sequential Read
|
Up to 7,000 MB/s * Performance may vary based on system hardware
& configuration
|
|
Sequential Write
|
Up to 5,000 MB/s * Performance may vary based on system hardware
& configuration
|
|
Random Read (4 KB, QD32)
|
Up to 1,000,000 IOPS * Performance may vary based on system hardware
& configuration
|
|
Random Write (4KB, QD32)
|
Up to 1,000,000 IOPS * Performance may vary based on system hardware
& configuration
|
|
Environment
|
|
|
Average Power Consumption (system level)
|
*Average: 6.2 W*Maximum: 8.9 W (Burst mode)* Actual power consumption
may vary depending on system hardware & configuration
|
|
Power consumption (Idle)
|
Max. 35 mW * Actual power consumption may vary depending on system
hardware & configuration
|
|
Allowable Voltage
|
3.3 V ± 5 % Allowable voltage
|
|
Reliability (MTBF)
|
1.5 Million Hours Reliability (MTBF)
|
|
Operating Temperature
|
0 - 70 ℃ Operating Temperature
|
|
Shock
|
1,500 G & 0.5 ms (Half sine)
|
|
Software
|
|
|
Management SW
|
Magician Software for SSD management
|
