  2. TP-Link VIGI C440 (2.8mm/4mm) 4MP Full-Color Turret Network Camera

TP-Link VIGI C440 (2.8mm/4mm) 4MP Full-Color Turret Network Camera

https://shop.uniq.com.ph/web/image/product.template/884/image_1920?unique=e18e154
(0 review)

Key Features

  • 4MP Ultra-High Definition
  • 24h Full-Color
  • Smart Detection
  • H.265+ Smart Coding
  • PoE/12V DC
  • Remote Monitoring

PRODUCT DETAILS



₱ 0.00 0.0 PH ₱ 0.00 VAT Included

₱ 0.00000 VAT Included

Not Available For Sale

  • Lens

This combination does not exist.

Contact Us
Pre-Order (Ship in 7 Days)

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days



CAMERA

Image Sensor1/3” Progressive Scan CMOS
Shutter Speed1/3 to 1/10000 s
Slow ShutterYes
Aperture2.8 mm: F1.6
4 mm: F1.6
LensFixed focal lens (2.8 mm / 4 mm)
Lens MountM12
Minimum Illumination0 lux with IR/white Light
Day/Night MechanismIR Cut Filter
Day/Night SwitchUnified/ Scheduled/ Auto
Digital Noise Reduction3D DNR
WDRDWDR
IR Working Distance30m
Pan/Tilt RangePan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360°
Illumination Distance30m (LED)
Viewing Angle(2.8 mm) Horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 122°
(4 mm) Horizontal FOV: 79°, vertical FOV: 43°, diagonal FOV: 93°

LENS

TypeFixed Focal Lens
Focal Length2.8/4 mm
Aperture2.8 mm: F1.6
4 mm: F1.6
FOV2.8mm:
Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122°
4mm:
Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
Lens MountM12
DORI Distance2.8 mm
Detect: 64 m (209 ft)
Observe: 27 m (87 ft)
Recognize: 13 m (42 ft)
Identify: 6 m (21 ft)

4 mm
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft)

Angle Adjustment (Manual)

RangePan: 0° to 360°,
Tilt: 0° to 85°
Rotate: 0° to 360°
ILLUMINATOR
IR LEDQuantity: 2
Range: 30m
Wavelength: 850nm
White LEDQuantity: 2
Range: 30m
Illuminator On/Off ControlUnified/ Scheduled/ Auto

VIDEO

Max. Resolution2560 X 1440
Main StreamFrame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080
Sub-StreamFrame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080
Bit Rate ControlCBR, VBR
Video CompressionMain Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
H.264 TypeMain Profile/High Profile
H.264+Main Stream Supported
H.265 TypeMain Profile
H.265+Main Stream Supported
Video Bit RateMain Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps


Image SettingsMirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image EnhancementBLC/3D DNR/HLC/SmartIR
Wide Dynamic RangeDWDR
SNR≥ 52 dB
Image Parameters SwitchYes
Privacy MaskUp to 4 Masks
ROI1 Region
OSD SettingYes

AUDIO

Audio CommunicationTwo-Way Audio
Audio InputYes
Audio OutputYes
Audio CompressionYes
Audio Sampling Rate8KHz
Environment Noise FilteringYes
Audio Bit Rate64 Kbps(G.711 alaw)

NETWORK

ProtocolTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIFYes
APIONVIF
Simultaneous Live View3 Main Streams & 3 Sub-Streams
Web BrowserGoogle Chrome® 57 and above
Firefox® 52 and above
Safari® 11 and above
Microsoft® Edge 91 and above
CloudYes
SecurityPassword Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

ALARM AND EVENT MANAGEMENT

Smart EventArea Intrusion Detection, Line-Crossing Detection, People Detection
Basic EventMotion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm LinkageMemory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage MethodN/A
Output NotificationMessage Push

INTERFACES

Network Interface1 RJ45 10/100M Self-Adaptive Ethernet Port
Audio InputBuilt-in Microphone
Audio OutputBuilt-in Speaker
AlarmN/A
Reset ButtonYes
PowerDC Power Port
ButtonReset Button
On-board StorageBuilt-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
Built-in MicrophoneYes; Records Anything Going on within a 15-ft Radius of the Camera
Built-in SpeakerYes
AudioN/A

GENERAL

Operating Temperature-30–60 °C
Storage Temperature-40–60 °C
Operating Humidity95% or Less (Non-Condensing)
Storage Humidity95% or Less (Non-Condensing)
Dimensions( H X W X D )123 × 123 × 84 mm
MaterialPlastic
General FeaturesTwo Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Net Weight0.25 Kg
Gross Weight0.4 Kg
Power Consumption12V DC: Max 5.5W
PoE: Class 0
Power Supply12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)
ProtectionN/A
Product Dimensions (L x W x H)123× 83× 123 mm
CertificationsCE, FCC, RCM, BSMI, VCCI, RoHS

 VIDEO/IMAGE

Video CompressionMain Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
Frame Rate & ResolutionsMain Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080

Sub-Stream
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 640x480, 352x288, 320x240
Image SettingsMirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Image EnhancementBLC/3D DNR/Prevent Overexposure to Infrared Light
Video Bit RateMain Stream: 256 Kbps to 4 Mbps
Sub-Stream: 64 Kbps to 512 Kbps

SMART FEATURE-SET

Smart EventArea Intrusion Detection, Line-Crossing Detection
Basic EventMotion Detection, Video Tampering Detection, Exception ( illegal login)
Linkage MethodTrigger Notification: ONVIF, HTTPS
Region of Interest1 Region

For additional version information, please go to the support page.




  • What's in the box: 1x Tp-Link VIGI C440(2.8mm/4mm) 4MP Full-Color Turret Network Camera, Quick Start Guide, Power Adapter, Mounting Accessories
