Display
|
|
|
Panel Size
|
65"
|
|
Panel Type
|
TFT LCD Module with DLED Backlight. IPS
|
|
Display Area (mm)
|
1428.48(H) × 803.52(V) (64.5” diagonal)
|
|
Aspect Ratio
|
16:9
|
|
Resolution
|
UHD 3840x2160(Pixels)
|
|
Colors
|
1.07B colors
|
|
Brightness
|
350 nits
|
|
Contrast Ratio
|
5000:1 (max. with DCR enabled)
|
|
Response Time
|
8ms
|
|
Viewing Angles
|
H=178, V=178
|
|
Backlight Life
|
50,000 Hours (8 hours of use per day)
|
|
Surface Treatment
|
Hardness: 7H Anti-glare coating
|
|
Orientation
|
Landscape
|
|
Platform
|
|
|
Processor
|
Quad-core ARM Cortex (A55*4 )
|
|
RAM
|
4GB DDR4
|
|
Storage
|
32 GB
|
|
Touch
|
|
|
Type/ Tech
|
Ultra Fine Touch Technology
|
|
Touch Point
|
40 points touch
|
|
INPUT
|
|
|
HDMI
|
HDMI-IN 2.0 x 3 (3840x2160 @60Hz)
|
|
RGB / VGA
|
x1
|
|
Audio
|
x1
|
|
RS232
|
x1
|
|
OPS
|
x1 (Optional Intel Standard OPS)
|
|
WiFi
|
x1 (Optional VB-WIFI-002/VB-WIFI-004/VSB-050)
|
|
OUTPUT
|
|
|
HDMI
|
HDMI 2.0 x1
|
|
Audio
|
x1
|
|
SPDIF
|
x1
|
|
LAN
|
|
|
RJ45
|
x2
|
|
USB
|
|
|
Type A
|
USB3.0 x4 (Front x2, Rear x2)；USB2.0 x1 |
|
Type B
|
x2 (Front x1, Rear x1)
|
|
Type C
|
Frontx1 (PD65W + DP1.2 + Data USB2.0 + 10M/100M
sharing)
|
|
SPEAKERS
|
16W x 2
|
|
Top Camera Plate
|
Yes
|
|
Embedded OS
|
Android 11
|
|
Bundle Software
|
|
|
Basic Annotation Software
|
myViewBoard Whiteboard
Pro Annotation Software
|
|
myViewBoard for Windows (Embedded in optional
Windows Slot-in PC)
Wireless Presentation
|
myViewBoard Display
|
|
Wireless Presentation with Touch Feedback
|
Viewboard Cast: Yes
|
|
Special Features
|
|
|
All-in-one USB port
|
(combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to
all channels.
|
|
Simple LAN sharing between IFP and slot-in device
|
10/100M for Android & Slot-in PC
|
|
Light Sensor
|
Yes
|
|
Power
|
|
|
Voltage
|
100-240V AC
|
|
Consumption
|
On:
On:99W ; Off: ≤ 0.5W
|
|
ERGONOMICS
|
|
|
Wall Mount (VESA® )
|
600x400
|
|
OPERATING CONDITIONS
|
|
|
Temperature (º C)
|
0°C to 40°C
|
|
Humidity
|
20% ~ 80% RH non-condensing
|
|
DIMENSIONS (W x H x D)
|
|
|
Physical (inch / mm)
|
1488 x 897 x 88 mm / 58.6 x 35.3 x 3.5 in
|
|
Packaging (inch / mm)
|
1628x1005x208 mm / 64.1x 39.6x 8.2in
|
|
WEIGHT
|
|
|
Net (lb / kg)
|
77.1lb/34.95kg
|
|
Gross (lb / kg)
|
98.5 lb/44.7kg
|
|
REGULATIONS
|
FCC/ICES003, EPEAT, CE EMC, LVD or
CB, RoHS Green BOM & RoHS DoC, ErP, REACH SVHC List & DoC, EEL, WEEE,
BSMI,BIS
|
|
|
|
