Display
|
|
|
Panel
Size
|
86"
|
|
Panel
Type
|
TFT
LCD Module with DLED Backlight. IPS
|
|
Display
Area (mm)
|
1913.04(H)
x 1083.96 (V)
|
|
Aspect
Ratio
|
16:9
|
|
Resolution
|
UHD
3840x2160(Pixels)
|
|
Colors
|
1.07B
colors
|
|
Brightness
|
350
nits
|
|
Contrast
Ratio
|
5000:1
(max. with DCR enabled)
|
|
Response
Time
|
8ms
|
|
Viewing
Angles
|
H=178,
V=178
|
|
Backlight
Life
|
50,000
Hours (8 hours of use per day)
|
|
Surface
Treatment
|
Hardness:
7H Anti-glare coating
|
|
Orientation
|
Landscape
|
|
Platform
|
|
|
Processor
|
Quad-core
ARM Cortex (A55*4 )
|
|
RAM
|
4GB
DDR4
|
|
Storage
|
32 GB
|
|
Touch
|
|
|
Type/
Tech
|
Ultra
Fine Touch Technology
|
|
Touch
Point
|
40
points touch
|
|
INPUT
|
|
|
HDMI
|
HDMI-IN
2.0 x 3 (3840x2160 @60Hz)
|
|
RGB /
VGA
|
x1
|
|
Audio
|
x1
|
|
RS232
|
x1
|
|
OPS
|
x1
(Optional Intel Standard OPS)
|
|
WiFi
|
x1
(Optional VB-WIFI-002/VB-WIFI-004/VSB-050)
|
|
OUTPUT
|
|
|
HDMI
|
HDMI
2.0 x1
|
|
Audio
|
x1
|
|
SPDIF
|
x1
|
|
LAN
|
|
|
RJ45
|
x2
|
|
USB
|
|
|
Type
A
|
USB3.0
x4 (Front x2, Rear x2)；USB2.0 x1
|
|
Type
B
|
x2
(Front x1, Rear x1)
|
|
Type
C
|
Frontx1
(PD65W + DP1.2 + Data USB2.0 + 10M/100M sharing)
|
|
SPEAKERS
|
16W x
2
|
|
Top
Camera Plate
|
Yes
|
|
Embedded
OS
|
Android
11
|
|
Bundle
Software
|
|
|
Basic
Annotation Software
|
myViewBoard
Whiteboard
Pro
Annotation Software
|
|
myViewBoard
for Windows (Embedded in optional Windows Slot-in PC)
Wireless
Presentation
|
myViewBoard
Display
|
|
Wireless
Presentation with Touch Feedback
|
Viewboard
Cast: Yes
|
|
Special
Features
|
|
|
All-in-one
USB port
|
(combine
slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels.
|
|
Simple
LAN sharing between IFP and slot-in device
|
10/100M
for Android & Slot-in PC
|
|
Light
Sensor
|
Yes
|
|
Power
|
|
|
Voltage
|
100-240V
AC
|
|
Consumption
|
On:154W
; Off: ≤ 0.5W
|
|
ERGONOMICS
|
|
|
Wall
Mount (VESA® )
|
800x600
|
|
OPERATING
CONDITIONS
|
|
|
Temperature
(º C)
|
0°C
to 40°C
|
|
Humidity
|
20% ~
80% RH non-condensing
|
|
DIMENSIONS
(W x H x D)
|
|
|
Physical
(inch / mm)
|
1957
x 1160 x 100 mm / 77 x 45.7 x 3.9 in
|
|
Packaging
(inch / mm)
|
2110
x 1283 x 225 mm /83 x 50.5 x 8.9 in
|
|
WEIGHT
|
|
|
Net
(lb / kg)
|
129.1lb/58.55kg
|
|
Gross
(lb / kg)
|
167.3lb/75.9kg
|
|
REGULATIONS
|
FCC/ICES003,
EPEAT, CE EMC, LVD or CB, RoHS Green BOM & RoHS DoC, ErP, REACH SVHC
List & DoC, EEL, WEEE, BSMI,BIS
|
|
|
|
